Benefits:
Specifications:
| Model | Optics | Electric | Size (External x Internal x Height) | Weight (g) | |||||
| Color | LED Row | Angle | Working Distance (mm) | Voltage (V) | W (2) * | ||||
| Red | White, Blue, Green | ||||||||
| CRL-32-2-70 | Red, White, Blue, Green | 2 | 70 | 15-25 | 24 | 1 | 1.9 | 32x10x16 | 25 |
| CRL-35-2-90 | Red, White, Blue, Green | 2 | 90 | 15 | 24 | 1.3 | 2.3 | 35x14x18 | 33 |
| CRL-42-2-65 | Red, White, Blue, Green | 2 | 65 | 19-29 | 24 | 1.6 | 2.5 | 42x18x18 | 40 |
| CRL-50-3-45 | Red, White, Blue, Green | 3 | 45 | 4-16 | 24 | 2.6 | 3 | 50x20x19 | 58 |
| CRL-50-2-60 | Red, White, Blue, Green | 2 | 60 | 22-31 | 24 | 1.5 | 2.7 | 50x24x16 | 46 |
| CRL-50-2-75 | Red, White, Blue, Green | 2 | 75 | 56-72 | 24 | 1.8 | 2.4 | 50x28x16 | 43 |
| CRL-50-2-90 | Red, White, Blue, Green | 2 | 90 | 26 | 24 | 2 | 3.5 | 50x25x19 | 52 |
| CRL-66-3-60 | Red, White, Blue, Green | 3 | 60 | 27-43 | 24 | 3.8 | 4 | 66x30x17 | 79 |
| CRL-70-3-45 | Red, White, Blue, Green | 3 | 45 | 12-35 | 24 | 6.8 | 9 | 70x38x21 | 105 |
| CRL-70-3-60 | Red, White, Blue, Green | 3 | 60 | 28-46 | 24 | 3 | 4.5 | 70x30x20 | 110 |
| CRL-70-3-90 | Red, White, Blue, Green | 3 | 90 | 36 | 24 | 3.5 | 4.8 | 70x35x22 | 115 |
| CRL-72-3-75 | Red, White, Blue, Green | 3 | 75 | 38 | 24 | 3 | 5 | 70x35x22 | 115 |
| CRL-74-3-60 | Red, White, Blue, Green | 3 | 60 | 28-45 | 24 | 2.5 | 5 | 74x35x20 | 107 |
| CRL-90-4-45 | Red, White, Blue, Green | 4 | 45 | 50-90 | 24 | 6.5 | 4.5 | 90x50x20 | 160 |
| CRL-90-4-70 | Red, White, Blue, Green | 4 | 70 | 68-103 | 24 | 3.5 | 8.5 | 90x50x20 | 160 |
| CRL-90-6-80 | Red, White, Blue, Green | 6 | 80 | 80-120 | 24 | 8 | 11.5 | 90x30x20 | 170 |
| CRL-100-4-70 | Red, White, Blue, Green | 4 | 70 | 100-150 | 24 | 4 | 9 | 100x55x17 | 180 |
| CRL-100-5-90 | Red, White, Blue, Green | 5 | 90 | 100-150 | 24 | 8 | 14 | 100x40x20 | 190 |
| CRL-110-5-60 | Red, White, Blue, Green | 5 | 60 | 28-45 | 24 | 5 | 13 | 110x60x25 | 190 |
| CRL-114-9-80 | Red, White, Blue, Green | 9 | 80 | 80-130 | 24 | 17.5 | 24.0 | 114x30x20 | 250 |
| CRL-120-4-45 | Red, White, Blue, Green | 4 | 45 | 50-110 | 24 | 10.5 | 11.5 | 120x80x18 | 250 |
| CRL-120-4-50 | Red, White, Blue, Green | 4 | 50 | 30-48 | 24 | 8.3 | 13.9 | 120x80x21 | 210 |
| CRL-120-5-75 | Red, White, Blue, Green | 5 | 75 | 134-100 | 24 | 8.2 | 14 | 120x65x17 | 250 |
| CRL-120-6-90 | Red, White, Blue, Green | 6 | 90 | 120-200 | 24 | 8.5 | 13 | 120x50x18 | 270 |
| CRL-140-5-70 | Red, White, Blue, Green | 5 | 70 | 70-100 | 24 | 14.3 | 16.5 | 140x85x18 | 250 |
| CRL-150-9-90 | Red, White, Blue, Green | 9 | 90 | 150-240 | 24 | 10 | 16 | 150x25x22.5 | 420 |
| CRL-164-5-70 | Red, White, Blue, Green | 5 | 70 | 130-160 | 24 | 17.2 | 19.5 | 164x105x20 | 450 |
| CRL-180-4-60 | Red, White, Blue, Green | 4 | 60 | 106-140 | 24 | 8.2 | 16 | 180x126x21 | 500 |
| CRL-180-8-80 | Red, White, Blue, Green | 8 | 80 | 360-380 | 24 | 18.8 | 25 | 180x100x20 | 650 |
| CRL-210-7-60 | Red, White, Blue, Green | 7 | 60 | 116-166 | 24 | 15 | 24 | 210x145x25 | 700 |
The LW300 series features a 100% waterproof stainless-steel enclosure specially designed for the food industry and washdown environments where water and harsh detergents are present. The LW300 features an integrated constant current driver built into the light and runs in continuous operation mode. NPN or PNP trigger signal inputs can be used to control the on/off input of the light. The intensity of the light can be controlled via 1-10VDC analog signal line or the onboard manual potentiometer. Daisy-chain up to six LW300 lights together.
The modular design of the LXB300 linear light, part of the Direct Connect Linear Light Series, offers integrated light-to-light connectors, eliminating the need for cable connectors to string lights together. The LXB300 features a factory-installed 2447 diffuser backlight lens and is a viable option for silhouetting objects. The light operates in continuous operation. This innovative design requires a power connection to the first light but eliminates the need for jumper cables to pass power through to the next, enabling tailored-length solutions in increments of 300 mm. Direct connect up to eight LXB300 together.
The L300G2 linear light features an integrated Multi-Drive™ driver that can produce up to 390,000 lux. NPN or PNP triggers can control the light for either OverDrive™ or continuous operation. Control light intensity via 1 – 10 VDC analog intensity line or remotely using SmartVisionLink™. Daisy-chain up to six L300G2 lights in series using a standard 5-pin M12 jumper cable.
The LCZE300 is a SmartVisionLink™-enabled linear light. With the addition of the BTM-1000 Bluetooth module, the LCZE300 can be wirelessly adjusted for intensity levels. The LCZE300 can be connected in a series of up to six lights, either through direct-connect or daisy-chain, to create a total of 6 independently controllable lighting zones.
