| # | Part Number | Magnification | Image Circle Dia (mm) | Max Sensor Size | 1/3" FOV (mm) | 1/2" FOV (mm) | 2/3" FOV (mm) | Working Distance (mm) | Working f/N | Distortion (%) | Depth of Field (mm) | Mount | Phase Adjustment | Length (mm) | Front Dia (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | RT-HR-6M-71 | 6.000 | 11.0 | 2/3″ | 0.80 x 0.60 | 1.07 x 0.80 | 1.42 x 1.18 | 71.1 | 41.1 | < 0.90 | 0.1 | C | Yes | 107.9 | 18.0 |
| 2 | RT-HR-4M-71 | 4.000 | 11.0 | 2/3″ | 1.20 x 0.90 | 1.60 x 1.20 | 2.13 x 1.77 | 71.1 | 29.0 | < 0.82 | 0.1 | C | Yes | 100.0 | 18.0 |
| 3 | RT-HR-2M-71 | 2.000 | 11.0 | 2/3″ | 2.40 x 1.80 | 3.20 x 2.40 | 4.25 x 3.55 | 71.0 | 18.5 | < 0.34 | 0.3 | C | Yes | 97.0 | 18.0 |
| 4 | RT-HR-1M-71 | 1.000 | 11.0 | 2/3″ | 4.80 x 3.60 | 6.40 x 4.80 | 8.50 x 7.09 | 71.0 | 15.6 | < 0.01 | 0.9 | C | Yes | 116.1 | 18.0 |
| 5 | RT-HR-6M-110 | 6.000 | 11.0 | 2/3″ | 0.80 x 0.60 | 1.07 x 0.80 | 1.42 x 1.18 | 110.0 | 55.6 | < 0.48 | 0.2 | C | Yes | 112.1 | 18.0 |
| 6 | RT-HR-4M-110 | 4.000 | 11.0 | 2/3″ | 1.20 x 0.90 | 1.60 x 1.20 | 2.13 x 1.77 | 110.0 | 39.2 | < 1.03 | 0.2 | C | Yes | 92.5 | 18.0 |
| 7 | RT-HR-2M-110 | 2.000 | 11.0 | 2/3″ | 2.40 x 1.80 | 3.20 x 2.40 | 4.25 x 3.55 | 110.0 | 23.8 | < 1.52 | 0.4 | C | Yes | 85.3 | 18.0 |
| 8 | RT-HR-1M-110 | 1.000 | 11.0 | 2/3″ | 4.80 x 3.60 | 6.40 x 4.80 | 8.50 x 7.09 | 110.0 | 16.7 | < 0.06 | 1.0 | C | Yes | 125.5 | 18.0 |
Features and Benefits:
Applications:
Features and Benefits:
Applications:
![Opto Engineering – Telecentric [TCLWD SERIES]](https://www.jm-vistec.com/wp-content/uploads/2026/03/TCLWD-series-1-300x204.jpg)
TCLWD is a range of telecentric lenses specifically designed for electronic and semiconductor Automated Optical Inspection (AOI) and tool presetting machines.
All these lenses feature a working distance of 132 mm while ensuring excellent optical resolution, high telecentricity and low distortion, thus matching and even exceeding the industrial requirements for the target applications.
The long working distance allows for extra space, which is essential if you need to install illumination, pick-up tools or provide the necessary separation from hazardous production processes.
In addition to the long working distance, TCLWD optics deliver a numerical aperture large enough to take advantage of high resolution / small pixel size cameras, making these lenses a perfect match for general-purpose 2D measurement systems.
CoaXpress is a recently developed camera standard utilizing a single coax cable for transfer rates of up to 6.25 Gbps. Utilizing precision 75 ohm impedance and 100% sweep tested cable, Intercon 1 CoaXPress cable assemblies are JIIA certified to be CoaXPress compliant
By combining materials like crush resistant gas-injected polyethylene compound that reduces attenuation and extends operating band width. Intercon 1 provides the most robust industrial assemblies available. These assemblies are designed to function within a broad range of environmental conditions.
