With a resolution of 47 MP 5.5µm pixels and global shutter, the SHR features a low-noise half-frame CCD multi-tap sensor that is in a class of its own. State-of-the-art tap sensor balancing and the highest structural precision of the sensor adjustment in a massive housing make the SHR with its lens shading correction the ideal partner for the most demanding optical applications.
5.5 µm pixel pitch, global shutter
Tap balancing with superb image homogeneity
User defined lens shading correction
User defined pixel correction
Integrated 4-channel LED strobe controller
72mm lens mount
Industrial TTL-24V I/O interface with SafeTrigger, programmable logic functions, sequencers and timers, RS232
The SHR Camera Link fits seamlessly into existing Camera Link based infrastructures. The possibilities offered by Camera Link also permit features that are not feasible with other types of interfaces.
The RAZOR series cameras incorporate the most popular sensor resolutions with the ultimate in image performance, frame rates and economy. With scalable 1, 2 or 4 output links, RAZOR cameras offer users an easy and very cost-effective upgrade path to existing Camera Link systems.
Polarized cameras are equipped with special image sensors and measure the polarization properties of light that are imperceptible to the human eye. The degree of polarization and the planes of polarization can be determined from a single image. Global shutter, high resolution, high optical dynamic range and high frame rate allow detailed structural analysis of even moving objects.
Despite the special sensors, the EXO Polarized is a standard industrial camera for use with standard lenses. The integrated 4-channel strobe controller supports complex lighting and analysis setups.
GenICam 3.0, GigE Vision and USB3 interface
LUT, ROI, Burst Mode
Electrical and optical inputs
Up to 60°C operating temperature
Integrated 4-channel strobe controller
Industrial TTL-24V I/O interface with SafeTrigger, logic functions, programmable sequencers and timers, RS232 interface
