Features:
Product Model:
| Product Model | Resolution | Frame Rate | Port | Sensor | Pixel Size | Mono/Color |
|---|---|---|---|---|---|---|
|
AB5131CU000E
|
1280 × 1024 | 208 fps | USB3.0 | PYTHON 1300 | 4.8 × 4.8 |
 |
|
AB5131MU000E
|
1280 × 1024 | 208 fps | USB3.0 | PYTHON 1300 | 4.8 × 4.8 |
 |
|
AB3600MU000E
|
3072 × 2048 | 60 fps | USB3.0 | IMX178 | 2.4 × 2.4 |
|
|
AB3600CU000E
|
3072 × 2048 | 60 fps | USB3.0 | IMX178 | 2.4 × 2.4 |
|
|
AB3A20MU000E
|
4000 × 3000 | 30 fps | USB3.0 | IMX226 | 1.85 × 1.85 |
|
|
AB3A20CU000E
|
4000 × 3000 | 30 fps | USB3.0 | IMX226 | 1.85 × 1.85 |
|
|
AB3138MU000E
|
1280 × 1024 | 201 fps | USB3.0 | SS | 4.0 × 4.0 |
|
|
AB3138CU000E
|
1280 × 1024 | 201 fps | USB 3.0 | SS | 4.0 × 4.0 |
|
|
AB3600CU010E
|
3072 × 2048 | 60 fps | USB3.0 | IMX178 | 2.4 × 2.4 |
|
|
AB3600MG000E
|
3072 × 2048 | 18 fps | GigE | IMX178 | 2.4 × 2.4 |
|
Key Features:
Highest resolution with large pixels and large sensor format: The SHR shines with up to 245 MP resolution when the task at hand requires uncompromising image quality.
Large pixels have many advantages when it comes to image quality in cameras, the physics here are clear. Some high-end tasks require the highest resolutions and impeccable image quality, which cannot be achieved without correspondingly large pixels for the optimum transfer function. This also applies to the highest resolutions. Tasks made for the SHR series.
Large sensors require special care in the camera to ensure a homogeneous image. Shading correction for demanding optical tasks and user-defined defect pixel correction ensure outstanding linearity, homogeneity and low noise.
We connect CMOS sensors in this category with the most powerful interfaces in order to make full use of the sensor’s high data rates. All cameras in the SHR series offer extensive I/O functions with sequencer and integrated strobe controller.
Highest resolution with optimized frame rate
Sony CMOS sensors with rolling and global shutter
Mono and Color (Bayer Pattern, Auto White Balance)
512 MB internal image memory
8 or 12 bit transmission
M72 thread (FFD 19.55)
User-defined Defect Pixel Correction
ROI, Look Up Table, Binning, Gamma, Offset
GenICam compatible
Exposure time: Trigger manual/auto/external
Integrated multi-channel LED strobe controller
Industrial TTL-24V I/O interface with SafeTrigger, programmable logic functions, sequencers and timers, RS23
High structural precision in sensor alignment and housing ensures precise image reproduction and a secure hold for the camera mount, adapter and lenses. The medium-format SHR is equipped with a standardized M72 thread and can therefore be used with a wide range of lenses and adapter rings. Thanks to the short flange distance of 19.55 mm, the highest quality lens systems can be individually adapted for almost any task.
Properties of light that are invisible to humans can be made visible with cameras from SVS-Vistek. These cameras extend the standard industrial image processing system in terms of polarization planes or wavelengths from infrared to ultraviolet.
Wavelengths from infrared to ultraviolet enable invisible markings, the identification of materials and much more. Properties of light such as polarization facilitate industrial inspection in many industrial applications with non-metallic materials. We offer highly sensitive cameras for technical and biological applications.
Our EXO and FXO series SWIR cameras with SONY SenSWIR sensor offer outstanding performance and precision to meet the most demanding industrial applications.
Whether for quality control, material analysis or scientific research – our UV technology opens up new possibilities for you and increases the efficiency of your processes.
Our polarized industrial cameras set new standards in industrial image processing by offering the unique ability to filter reflected light and thus make hidden details visible.
All of our special cameras for invisible properties of light are based on the proven camera concepts of the EXO series and the FXO series. While the EXO covers the established GigE Vision and USB3 Vision interfaces, the FXO series can provide the highest frame rates with its high-speed 10GigE and CoaXPress-12 interfaces.
A close thermal connection of the low-power optimized electronics and the sensor to the housing enables operating temperatures of up to 60°C. The integrated power I/O interface enables simple control tasks to be performed with hardware precision via the PLC functionality. Up to 4 LED lights can be controlled directly without additional drivers, ideal for the identification of materials. All Beyond Visible cameras from SVS-Vistek have the following features: Region of Interest (ROI), logical trigger functions (PLC) with programmable timers, sequencers and logic, electrical and optical inputs are specified with TTL-24V.
A wide variety of CMOS sensors are installed in the EXO. It offers a wide range of interfaces such as GigE Vision, Camera Link and USB3 Vision, all with an integrated strobe controller.
The precisely crafted unibody housing and a wide range of CMOS sensors from Sony and CMOSIS form the basis for this versatile industrial camera. The EXO is easy to integrate thanks to the large number of standardized mounting holes and offers a stable connection for any type of lens.
With an excellent image, outstanding temperature performance, multiple inputs, PLC functionality and a multichannel strobe controller, the EXO offers an extremely flexible, powerful and economical overall package.
Small, very robust, easy to integrate: The EXO Camera Link series offers resolutions from 2.3 to 20.2 MP.
The EXO series with GigE Vision interface offers cameras with resolutions from 1.6 to 24.5 MP.
Particularly versatile: The EXO series with USB3 interface offers resolutions from 2.3 MP (160 fps) to 31.4 MP (12 fps).
The EXO Tracer series with MFT mount is available with GigE Vision and USB3 interface.
A close thermal connection of the low-power optimized electronics and the sensor to the unibody housing enables operating temperatures of 60°C for most EXOs. The EXO is available with the established GigE Vision, Camera Link and USB3 Vision interfaces and supports the latest standards such as GenICam 3.0 and USB 3.1. In the tracer version, it controls all lens functions such as zoom, focus and iris with its MFT bayonet. The integrated power I/O interface enables simple control tasks to be performed with hardware precision via the PLC functionality and/or up to 4 LED lights to be controlled directly without additional drivers.
The EXO series therefore fulfills a wide range of different requirements: A robust and precise industrial camera, extremely scalable with a wide range of CMOS sensors, easy to integrate thanks to standardized pinouts and consistent dimensions, extremely flexible due to availability in the most important interface standards and rich in important features.
