Built for high-speed industrial inspection, the DM Optical 4K 7μ Line Scan Lens Series delivers sharp, uniform resolution for 4K line scan cameras with 7μm pixels. Optimized for web and surface inspection, these lenses provide minimal distortion and high contrast across the scan line — ensuring precise edge definition for detecting micro-defects and measuring dimensions in real time. Ideal for PCB, print, textile, and flat panel display applications where pixel-level accuracy and throughput are critical.
Features:
| # | Product Code | Focal Length | Max Image Circle | F.NO | Magnification Range | Standard Magnification | WD | O/I | Flange Distance | Mount | Filter Size |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 52320160 | 20mm | φ30 | 4.5-C | 0.02x-0.1x | 0.0358x | 557.4 | 619.1 | 12 | M42×P1 | M43×P0.75 |
| 2 | 52370150 | 25mm | φ32 | 2.8-16 | 0.03x-0.2x | 0.121x | 200 | 269.5 | 12 | M42×P1 | M49×P0.75 |
| 3 | 52400140 | 29mm | φ30 | 4.0-C | 0.05x-0.3x | 0.1x | 299.7 | 368 | 26 | V-Mount (φ42.5) | M35×P0.5 |
| 4 | 52470210 | 35mm | φ30 | 4.5-16 | 0.04x-0.1x | 0.08x | 508.49 | 574.5 | 37.42 | V-Mount (φ38) | M37×P0.75 |
| 5 | 52520230 | 40mm | φ43.2 | 2.8-22 | 0.04x-0.33x | 0.1x | 429.9 | 498.48 | 39.62 | V-Mount (φ38) | M37×P0.75 |
