I8 is a high resolution multi-spectrum CMOSTDI image sensor with embedded CCD pixels. The sensor is composed of 1 P zone and 4 B zones. P zone features 6K-pixel resolution with 128 TDI stages, pixel size 10um*10um. B zone features 1.5K-pixel resolution with 64 TDI stages, pixel size 40um*40um. It is designed
with radiation hardness to work reliably in the radiation environment.
Features
⚫ High sensitivity and high dynamic range
⚫ BSI with peak QE 80%
⚫ Highly Integrated SOC with on-chip clock driver, timing & control, ADC
⚫ Advanced design structure for better Full-Well and lower noise
⚫ Enhanced NIR performance
⚫ Super radiation hardness
Applications
LEO Satellite Observation.
| Parameter | P zone | B zone |
|---|---|---|
| Resolution | 6,144 px | 1,536 px |
| TDI stage | 128 | 64 |
| Pixel size | 10 µm × 10 µm | 40 µm × 40 µm |
| Full well | LFD: 160 Ke⁻ | 300 Ke⁻ |
| Total noise | < 45 e⁻ | < 60 e⁻ |
| Line rate | 80 KHz | 20 KHz |
| TDI direction | Bi-direction | Bi-direction |
| ADC | 14-bit | 14-bit |
| MTF | 0.50 | 0.50 |
| FPN | < 1.2% | < 1.2% |
| PRNU | < 1.5% | < 1.5% |
| TID | 50 Krad | 50 Krad |
| SEE | 75 MeV·mg/cm² | 75 MeV·mg/cm² |
Canon has been manufacturing CMOS sensors since 2000 for exclusive use in Canon products. Building on that expertise and success, Canon is now committed to starting external sales to collaborate with various industries. Canon CMOS sensors feature unique designs to meet the needs of demanding vision applications.
I7 is a high resolution multi-spectrum CMOSTDI image sensor with embedded CCD pixels. The sensor is composed of 1 P zone and 4 B zones. P zone features 12K-pixel resolution with 128 TDI stages, pixel size 7um*7um. B zone features 3K-pixel resolution with 64 TDI stages, pixel size 28um*28um. It is designed
with radiation hardness to work reliably in the radiation environment.
Features
High sensitivity and high dynamic range
BSI with peak QE 85%
Highly Integrated SOC with on-chip clock driver, timing & control, ADC
Advanced design structure for better Full-Well and lower noise
Enhanced NIR performance
Super radiation hardness
Applications
LEO Satellite Observation.
Industrial Inspection.
Scientific Research.
| Parameter | P zone | B zone |
|---|---|---|
| Resolution | 12,288 px | 3,072 px |
| TDI stage | 128 | 64 |
| Pixel size | 7 µm × 7 µm | 28 µm × 28 µm |
| Full well | 80 Ke⁻ | 240 Ke⁻ |
| Total noise | < 10 e⁻ | < 60 e⁻ |
| Line rate | 100 KHz | 25 KHz |
| TDI direction | Bi-direction | Bi-direction |
| ADC | 14-bit | 14-bit |
| MTF | 0.50 | 0.50 |
| FPN | < 1.2% | < 1.2% |
| PRNU | < 1.5% | < 1.5% |
| TID | 100 Krad | 100 Krad |
| SEE | 75 MeV·mg/cm² | 75 MeV·mg/cm² |
