The Canon IDCCFC Series (IDCCFC-659, IDCCFC-943, IDCCFC-1318) is a CIS type line scan camera by Canon Components, Inc., designed as the ultimate solution for glossy surface inspection. Featuring built-in custom designed diffuse illumination, it delivers reliable and consistent imaging on reflective and high-sheen materials where conventional cameras fall short.
Available in scanning widths up to 1318mm, the series supports resolutions of 600, 300, 200, and 150dpi in both color and monochrome modes, with scan speeds reaching up to 648MPM in monochrome fast mode. Operating on a single 24V power supply and Camera Link® compliant, it integrates easily into existing machine vision systems.
Ideal for a wide range of demanding inspection applications including metal, textile, film, web, wafer, measurement, and print.
The Canon IDCCFC Series (IDCCFC-165C, IDCCFC-330C, IDCCFC-476C) is a CIS type line scan camera developed by Canon Components, Inc. for industrial surface inspection applications. Designed as a slim, compact all-in-one unit, it integrates optics, illumination, and imaging into a single housing, eliminating the need for external lighting setups.
Available in three scanning widths, the series supports resolutions of 600, 300, 200, and 150dpi, with both color and monochrome modes and a scan speed of up to 36m/min at 600dpi color. It communicates via Camera Link® and is suited for demanding machine vision tasks including print inspection, film, measurement, and web inspection.
I7 is a high resolution multi-spectrum CMOSTDI image sensor with embedded CCD pixels. The sensor is composed of 1 P zone and 4 B zones. P zone features 12K-pixel resolution with 128 TDI stages, pixel size 7um*7um. B zone features 3K-pixel resolution with 64 TDI stages, pixel size 28um*28um. It is designed
with radiation hardness to work reliably in the radiation environment.
Features
High sensitivity and high dynamic range
BSI with peak QE 85%
Highly Integrated SOC with on-chip clock driver, timing & control, ADC
Advanced design structure for better Full-Well and lower noise
Enhanced NIR performance
Super radiation hardness
Applications
LEO Satellite Observation.
Industrial Inspection.
Scientific Research.
| Parameter | P zone | B zone |
|---|---|---|
| Resolution | 12,288 px | 3,072 px |
| TDI stage | 128 | 64 |
| Pixel size | 7 µm × 7 µm | 28 µm × 28 µm |
| Full well | 80 Ke⁻ | 240 Ke⁻ |
| Total noise | < 10 e⁻ | < 60 e⁻ |
| Line rate | 100 KHz | 25 KHz |
| TDI direction | Bi-direction | Bi-direction |
| ADC | 14-bit | 14-bit |
| MTF | 0.50 | 0.50 |
| FPN | < 1.2% | < 1.2% |
| PRNU | < 1.5% | < 1.5% |
| TID | 100 Krad | 100 Krad |
| SEE | 75 MeV·mg/cm² | 75 MeV·mg/cm² |
I8 is a high resolution multi-spectrum CMOSTDI image sensor with embedded CCD pixels. The sensor is composed of 1 P zone and 4 B zones. P zone features 6K-pixel resolution with 128 TDI stages, pixel size 10um*10um. B zone features 1.5K-pixel resolution with 64 TDI stages, pixel size 40um*40um. It is designed
with radiation hardness to work reliably in the radiation environment.
Features
⚫ High sensitivity and high dynamic range
⚫ BSI with peak QE 80%
⚫ Highly Integrated SOC with on-chip clock driver, timing & control, ADC
⚫ Advanced design structure for better Full-Well and lower noise
⚫ Enhanced NIR performance
⚫ Super radiation hardness
Applications
LEO Satellite Observation.
| Parameter | P zone | B zone |
|---|---|---|
| Resolution | 6,144 px | 1,536 px |
| TDI stage | 128 | 64 |
| Pixel size | 10 µm × 10 µm | 40 µm × 40 µm |
| Full well | LFD: 160 Ke⁻ | 300 Ke⁻ |
| Total noise | < 45 e⁻ | < 60 e⁻ |
| Line rate | 80 KHz | 20 KHz |
| TDI direction | Bi-direction | Bi-direction |
| ADC | 14-bit | 14-bit |
| MTF | 0.50 | 0.50 |
| FPN | < 1.2% | < 1.2% |
| PRNU | < 1.5% | < 1.5% |
| TID | 50 Krad | 50 Krad |
| SEE | 75 MeV·mg/cm² | 75 MeV·mg/cm² |
Pulse/Direction output (current source to drive opto-isolator of stepper/servo motor drive
Analog focus control output 0-10V (e.g. to feed servo-, piezo- or voice coil controllers in open or closed loop)
Analog Quality signal output 0-10V
Industrial equipment suitable robust I/O interfacing, power supply/ground isolation, protection circuits, supply 24-48V
Single connection to AF Sensor, all connections from MSG Autofocus to your machine going through the LAF-C2
Inputs for limit switches and safety stop
Pulse/Direction output (current source to drive opto-isolator of stepper/servo motor drive
Analog focus control output 0-10V (e.g. to feed servo-, piezo- or voice coil controllers in open or closed loop)
Analog quality signal output 0-10V
Ethernet communication to PC (RJ45 supports passive POE)
2x 3W isolated LED supply controlled by Auto Focus user interface
Industrial equipment suitable robust I/O interfacing, power supply/ground isolation, protection circuits, supply 24-48V
Inputs for limit switches and safety stop
Auto Focus Sensor for automated optical inspection (AOI) Systems and industrial microscopes
Analog Output of Focus Distance: 0-10V
Applicable to infinite corrected lenses from 1x to 100x magnification, VIS, IR, UV
The LAF4- ORB comes as a standalone Auto Focus sensor and provides an analog output to connect with an external stage amplifier or motor controller with analog close look Control input
UI interface
Easy Integration and Software implementation
Auto Focus & Tracking for automated optical inspection (AOI) Systems and industrial microscopes
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Full laser line with segment processing
Extreme robust focus results by interactive selection of best focus parameters
Motor controller interface with analog & digital outputs for a seamless closed loop integration with third party’s stepper motor-, piezo-, voice-coil- or servo drives
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Adjustable laser power limitation
User interface with enhanced network capabilities for multi sensor operation
Easy integration of UI functions into the customer software without software library needed
Full laser line with segment processing
The unique correlation processing focus technology enables auto focus where other laser or image auto focus systems fail
Extreme robust focus results by interactive selection of best focus parameters
Motor controller interface with analog & digital outputs for a seamless closed loop integration with third party’s stepper motor , piezo , voice-coil or servo drives
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Adjustable laser power limitation
User interface with enhanced network capabilities for multi sensor operation
Easy integration of UI functions into the customer software without software library needed
Adapters available for a range of different microscopes
Motor controller interface with analog & digital outputs for a seamless closed loop integration with third party’s stepper motor, piezo, voice-coil or servo drives
Unique Correlation Processing laser focus method
Full laser line with segment processing
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Adjustable laser power limitation
User interface with enhanced network capabilities for multi sensor operation
Easy integration of UI functions into the customer software without software library needed
Auto Focus & Tracking for automated optical inspection (AOI) Systems and industrial microscopes
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Built in optical protection against strong light or laser sources which can disturb the focus measurement
Full laser line with segment processing
Extreme robust focus results by interactive selection of best focus parameters
Motor controller interface with analog & digital outputs for a seamless closed loop integration with third party’s stepper motor-, piezo-, voice-coil- or servo drives
Applicable to Plan Apo lenses 1x-150x, VIS, IR & UV
Adjustable laser power limitation
User interface with enhanced network capabilities for multi sensor operation
Easy integration of UI functions into the customer software without software library needed
Automated microscope for single lens
Automated microscope
payload with lens changer
Automated microscope with rotary lens changer
Automated Differential Interference Contrast microscope
Automated wide field of view microscope for single lens
