Industrial Lens | JM Vistec | Tele-centric Lens

Showing 129–144 of 176 results

Schneider Emerald

Emerald’s Key Features:

Image circle: 43.2 mm – 90 mm
5 focal lengths: 28 mm – 100 mm
F-Mount lens and V48-Mount lens available
Covering a wide working distance range
Initial apertures: F2.2 – F5.6

Schneider Jade

Jade’s Key Features:

• 1.2″ (19.3 mm) max. sensor size

• Very high resolution down to 2.4µ pixel size

• Low chief ray angle suitable for all SONY Pregius™ generations

• C-Mount lens

• 5 focal lengths: 12 mm – 50 mm

• Initial aperture: F2.8

Schneider Onyx

Onyx’s Key Features:

Extremely fast lens with F0.95
1″ (16 mm) max. sensor size
C-Mount lens
Focal length: 25 mm

Schneider Opal

Opal’s Key Features:

• 1.1″ (17.6 mm) max. sensor size

• Very high resolution down to 2.4µ pixel size

• Low chief ray angle suits all SONY Pregius™ generations

• C-Mount lens

• Focal length: 12 mm

• Initial aperture: F2.8

Schneider Pyrite

Pyrite’s Key Features:

Image circle: 30 mm – 100 mm
11 focal lengths: 28 mm – 120 mm
Covering a wide working distance range
Lenses for specific magnifications available
Very low distortion and high resolution
V38-Mount, compatible to the V38 mounting system
Initial apertures: F2.8 – F5.6

Schneider Pyrite LF

Pyrite’s Key Features:

Focus tunable liquid lens included
Large working distance range
Fast focus within milliseconds
Large image circle

Schneider Sapphire

Sapphire’s Key Features:

Extremely high resolution down to 3.5µ pixel size
Image circle: 62.5 mm – 82 mm
Optimized for specific magnifications
11 magnifications available: 0.07x – 2.0x
Version with Beamsplitter available
Best azimuth marking
V70-Mount for easy installation

Schneider Sylvine

Sylvine’s Key Features:

Bilateral telecentric design
Very high resolution down to 2.4µ pixel size
2/3″ (11 mm) max. sensor size
C-Mount lens
5 magnifications: 0.2x – 1x

Schneider Thulite

Thulite’s Key Features:

2″ (32 mm) max. Sensor size
3 focal lengths: 35 mm, 50 mm and 75 mm
Very high resolution down to 2.4µ pixel size
Initial aperture: F2.8
M42 lens and TFL-Mount lens available
Covering a wide working distance range

Schneider Topaz

Topaz’s Key Features:

• Optimized for long working distances up to infinity

• Low chief ray angle suits all SONY Pregius™ generations

• 1.2″ (19.3 mm) max. sensor size (TOPAZ 2.4/6.5: 1.1″)

• C-Mount lens

• 6 focal lengths available: 6.5 mm – 50 mm

• Initial aperture: F2 – F2.8

• Motorized iris available

Schneider Tourmaline

Tourmaline’s Key Features:

• 1.3″ (24 mm) max. sensor size

• Resolution down to 2.4µ pixel size

• Low chief ray angle suits all SONY Pregius™ generations

• C-Mount lens and TFL-Mount lens available

• 8 focal lengths: 16 mm – 50 mm

• Initial aperture: F2 – F2.8

• Ruggedized and motorized iris for selected focal lengths

Schneider Turquoise

Turquoise’s Key Features:

1″ (16 mm) max. sensor size
C-Mount lens
3 focal lengths: 10 mm, 16 mm and 70 mm
Initial aperture: F1.8 – F2.2
Ruggedized and motorized iris available

Schneider Zirconia

Zirconia’s Key Features:

Image circle: 62.5 mm – 82 mm
High resolution down to 5µ pixel size
Optimized for specific magnifications
6 magnifications available: 0.1x – 2.0x
Version with beampslitter available
Best azimuth marking
V48-Mount for easy installation

ZEISS Biogon T* 2.8/21 M42-I

The ZEISS Classis lens family offers extraordinary image quality with high contrast for technical and industrial applications in addition to a precise fixture for focus and aperture. The outer design is characterized by a full-metal housing as well as a focus ring, which allows precise manual focusing.

Features:
• f/2.8 aperture
• Precise manual focusing
• Robust full-metal construction
• Fixation for focus and aperture
• Outstanding image quality
• Compact and lightweight
• For industrial cameras up to sensor sizes of 24×36 mm or 43mm line sensors

ZEISS Biogon T* 2/35 M42-I

Features:
• f/2 aperture
• Moderate wide-angle lens
• Precise manual focusing
• Robust full-metal construction
• Fixation for focus and aperture
• Outstanding image quality
• Compact and lightweight
• For industrial cameras up to sensor sizes of 24×36 mm or 43mm line sensors.

ZEISS C Sonnar T* 1.5/50 M42-I

Features:
• Fast 1.5 aperture
• compact standard lens
• Precise manual focusing
• Robust full-metal construction
• Fixation for focus and aperture
• Outstanding image quality
• Compact and lightweight
• For industrial cameras up to sensor sizes of 24×36 mm or 43mm line sensors.
