TC1220-12MPTC1620-12MPTC2520-12MPTC3520-12MPTC5020-12MP
Focal Length (mm)1216253550
Image Format (Inch)
4/3″
4/3″
4/3″
4/3″
4/3″
Resolution (Megapixel)1212121212
Pixel Size (μm)
4.7
4.74.74.74.7
Aperture (F)
2.0 — 22
2.0 — 22
2.0 — 22
2.0 — 22
2.0 — 22
Angle of View
75.46° x 61.08°
44.2 x 33.5°
40.6° x 31°
29.6° x 22.4°
20.9° x 15.7°
MountCCCCC
M.O.D. (m)0.150.10.150.20.3
Filter Size
M77mm P=0.75
M58mm P=0.75
M46mm P=0.75
M40.5mm P=0.5
M40.5mm P=0.5
Dimensions (φ) mm80
59.8
48
44.6
44.6
Dimensions (L) mm
84.4
85.9
82.7
54.9
53.7
Iris Control
Manual with Locking screw
Manual with Locking screw
Manual with Locking screw
Manual with Locking screw Manual with Locking screw
Focus Control
Manual with Locking screw
Manual with Locking screw
Manual with Locking screw
Manual with Locking screw Manual with Locking screw
Back Focal Length (mm)
18.93
21
22.43
18.65
20.29
Operating Temperature (°C ~ )
-10 — +55
-10 — +50
-10 — +50
-10 — +50
-10 — +50
Weight (g)447
338
250173170



TFM-100
Focal Length (mm)100mm Fixed
Image Format (Inch)φ43mm
Angle of View (HxV)24.5°
Aperture (F)
2.8 — 32
MountF
M.O.D. (m)0.3
Filter Size
M55mm P=0.75
Dimensions (φ) mm
70
Dimensions (L) mm
95
Iris Control
Manual
Focus Control
Manual
Back Focal Length (mm)
44.18
Operating Temperature (°C ~ )
-20 — +55
Weight (g)
514



KCM-05-65SRKCM-05D-65SRKCM-1-75SRKCM-1D-75SRKCM-2-65SRKCM-2D-65SRKCM-4-65SRKCM-4D-65SRKCM-1-110SRKCM-1D-110SRKCM-2-110SRKCM-2D-110SRKCM-4-110SRKCM-4D-110SR
Magnification0.50.5112244112244
O/I (mm) (Object to image distance)211.7211.7174.9174.9167167
237.6
237.6
258.1
258.1
Working Distance (mm)6565757565656565110110110110110110
D.O.F. (μ)360360710710180180710710180180
Resolution (μ)8.398.39
6.1
6.1
3.05
3.05
6.16.13.053.05
Working F No6.36.39.49.49.19.19.39.39.19.1
NA
0.04
0.04
0.0550.0550.110.110.0550.0550.110.11
Dimensions (L) mm129.1129.181.781.787.487.497.497.4
110
110
129.6129.6130.8130.8
Weight (g)1701809010090100100110120130
160
170
170180
Sensor Size (max.~) “2/32/3
2/3
2/32/32/32/32/32/32/32/32/32/32/3
Resolution (Megapixel)
5
5
2
2222222
Pixel Size (μm)
3.6
3.6
5.5
5.55.55.55.55.55.55.5



KCM-1-65CKCM-1D-65CKCM-2-65CKCM-2D-65CKCM-4-65CKCM-4D-65CKCM-1-110CKCM-1D-110CKCM-2-110CKCM-2D-110CKCM-4-110CKCM-4D-110C
Magnification112244112244
O/I (mm) (Object to image distance)177.7177.7145.4145.4210210213.6213.6
Working Distance (mm)656564.864.864.864.8110110110110110110
D.O.F. (μ)1140114030030016001600490490
Resolution (μ)9.69.6
5.1
5.113.413.48.48.4
Working F No14.214.21515202024.624.6
NA
0.035
0.0350.0660.0660.0250.0250.040.04
TV Distortion (%)0.110.11-0.03-0.030.060.06-0.03-0.03
Dimensions (L) mm95.295.263.163.176.5mm76.5mm82.5582.5586.186.191.12mm91.12mm
Weight (g)606937464040556442524545
Sensor Size (max.~) “
1/2
1/2
2/3
2/31/21/22/32/3

With over 60 years of technical experience and know-how in optics, Kowa is proud to present the next generation of crystal clear, super wide angle, fixed focal length lenses. In particular, Kowa’s 8.5mm F2.8 model is able to produce ultra HD resolution by applying high precision aspherical lens elements. This design allows our 8.5mm lens to have minimal distortion even though it projects a super wide angle of view.

Features

  • The 8.5mm focal length model (KOWA PROMINAR 8.5mm F2.8) achieves a realistic and large-scale imaging expression with a distortion value of only 0.12% even though it offers a diagonal angle of view of 106°.

    [Note] Some lenses of the micro four thirds system standard may not be mounted to the camera.

  • The model with a wide angle of view and a 12mm focal length (KOWA PROMINAR 12mm F1.8) has a bright F1.8 aperture, and its distortion value has also been reduced to 0.59%.

    [Note] Some lenses of the micro four thirds system standard may not be mounted to the camera.

  • The model with a 25mm standard focal length (KOWA PROMINAR 25mm F1.8) suited for use in a variety of shooting environments has a bright F1.8 aperture, and provides a sharp image.

    [Note] Some lenses of the micro four thirds system standard may not be mounted to the camera.

  • XD Lenses

    Kowa’s XD Lenses (extra-low dispersion glass), when combined with a concave lens possessing special dispersion properties, reduces a very high percentage of chromatic aberration.

  • デュアル リンク アイリス

    A dual Link Iris system makes it possible to choose silent or click aperture adjustment. Aperture settings can be changed in an instant to suit the photographic subject.

  • 9枚円形絞り

    The construction of the aperture blades with 9 elements makes it possible that the diaphragm shows a circle at all f-stops, creating a more natural impression.

  • 金属ボディ

    All internal parts are protected by a solid and rigid aluminium housing.
    The body feels reassuringly well made with good balance and weightiness in the hand and when attached to a camera body.

  • フローティング機構

    The floating mechanism system is effective in preventing malfunction and increasing the life of the lens. High optical performance was achieved in all photographic subject distances.

Features:

  • Design for machine vision application, excellent performance at short WD, less than 500mm
  • Reduce color aberration, compared with Conventional Fixed Focal Lens
  • TV distortion less than 0.1% (except for f4mm)
  • Possible to use for macro imaging without extension ring



Features:

  • f12mm, HF1218V is suitable for 25 Mega Pixel and 12 Mega Pixel
  • f16mm – f75mm are compatible with 1.1”- 1.2”
  • Suitable for different types of sensor
  • Excellent performance at macro imaging, compared with conventional Mega Pixel Fixed Focal lens
  • Stable performance at different working distance by floating design
  • Large aperture
  • Robust design, suitable for machine vision applications



Features:

  • f12mm, 16mm, 25mm, 35mm, 50mm, 75mm are available for Fixed Focal Lens
  • f16~50mm is available for Varifocal Lens
  • 400nm~950nm Focus Shift correction
  • Realizes color reproduction in color images
  • Super high resolution, Low distortion, and excellent uniformity of brightness
  • Line up : Extension ring for close-up purpose





Features:

  • HS0420H and HS0618H are designed for low distortion
  • Stable performance from macro to infinity (∞)
  • Suitable for 3 Mega Pixel (1/1.8″,2/3″)
  • High durability





Features:

  • Suitable for 1” and 1.1”( 3.45μm/pixel)
  • Compact design
  • Stable performance at different working distance, from macro to infinity by floating design
  • Robust design
  • f35mm, 50mm, 75mm and 100mm are suitable for 1.1” (φ17.4mm)



Features:

  • Available for SWIR image sensor 1”,1.1”, InGaAs Sensor
  • Special design to transmit SWIR 950 〜 1800 nm



Features:

  • Possible to capture wide view with c mount full size camera
  • Excellent relative illumination
  • Stable performance from macro to infinity by floating design



Features:

  • Focal length f3.5mm – f100mm, 10 models are available
  • Available for focus and iris lock screws
  • Suitable for various application

Features:

  • Suitable for Resistance against vibration
  • Focus : double nut and set screw
  • Possible to select iris : 2(OPEN) / 4/ 5.6 / 8
  • Compact design
  • 12 kinds of focal length are available





Features:

  • Line up for 12 kinds of High Magnification Telecentric Lens
  • Ultra high brightness and NA







Features:

  • Possible to use from visible ~ 2000nm
  • Design to transmit SWIR
  • Suitable for InGaAs Line sensor camera : 2K (10um – 12.5um ), 1K (25um )
  • Super high resolution, Low distortion, and excellent uniformity of brightness
