TCSM series is a unique family of bi-telecentric lenses for extremely accurate 3D dimensional measurement systems. All TCSM lenses are equipped with a high-precision Scheimpflug adjustment mechanism that fits any type of C-mount camera. Besides achieving very good focus at wide tilt angles, bi-telecentricity also yields incredibly low distortion. Images are linearly compressed only in one direction, thus making 3D-reconstruction very easy and exceptionally accurate.

The available magnifications ranges from 0.5x to 0.1x while the angle of view reaches 30°-45° to meet the measurement needs of triangulation-based techniques. The Scheimpflug mount tilts around the horizontal axis of the detector plane to ensure excellent pointing stability and ease of focus.

TCLWD3M series is a range of high resolution telecentric lenses specifically designed for electronic and semiconductor Automated Optical Inspection (AOI) and tool pre-setting machines. The long working distance allows for extra space, which is essential if you need to install illumination, pick-up tools or provide the necessary separation from hazardous production processes.
TCLWD3M lenses have been optimized to match up to the new 1.1” Sony sensor in order to deliver high resolution and superb image quality.

In addition to the long working distance, TCLWD3M optics deliver a numerical aperture large enough to take advantage of high resolution / small pixel size cameras, making these lenses a perfect match for general-purpose 2D measurement systems.

TCZRS series is a leading edge optical solution for imaging and measurement applications requiring both the flexibility of zoom lenses and the accuracy of fixed optics.

An upgraded version of TCZR lenses, the newly designed TCZRS lenses feature an extremely precise positioning system with a bipolar stepper motor and an incremental magnetic encoder, delivering exceptional magnification repeatability. Moreover, focusing and image-centering stability are guaranteed at every magnification position, thus avoiding recalibration at any given time.

Four different magnifications, featuring a total zoom range of 8x, can be selected through a dedicated remote control software.

Bi-telecentricity, high resolution and low distortion make these zoom lenses able to perform the same measurement tasks as classic telecentric lenses.

TC1MHR series features high-resolution telecentric lenses designed for sensors up to 1/1.2” and is the perfect choice for advanced metrology applications. Our TC1MHR series delivers unmatched resolution thanks to the low F# as well as low distortion and homogeneous image quality while offering the best performance-to-price ratio.

TC1MHR lenses feature a compact and robust design that allows easy integration in industrial environments. Additionally, the camera phase can be easily adjusted by simply loosening the set screws positioned in the eyepiece.
